Copymaster3D Turbo PLA High Speed
- Item Id 30095
- Variation ID 12402
- EAN 5060848216211
- Mfg part No, CM-TPLA-001-1-175
Basic Data | |
Material | PLA |
Diameter | 1,75 mm |
Weight | 1,00 kg |
Length | 353 m |
Printing Parameter | |
Recommended Min Print Temp | 210 ºC |
Recommended Max Print Temp | 240 ºC |
Recommended Min Bed Temp | 55 ºC |
Recommended Max Bed Temp | 70 ºC |
Recommended Min Print Speed | 50 mm/s |
Recommended Max Print Speed | 500 mm/s |
Recommended Max Fan Speed | 100 % |
Recommended Retraction Max | 40 mm |
General | |
Specific Gravity | 1,1783 g/cm3 ISO 1183 |
Temperature | |
Vicat softening temp | 62 °C ISO 306 |
Heat Deflection Temp | 51,9 °C ISO 75 |
Tensile | |
Tensile Strength | 41,58 MPa ISO 527 |
Tensile modulus | 348,017 MPa ISO 527 |
Elongation | |
Elongation at yield | 9,050 % ISO 527 |
Elongation at Break | 17,427 % ISO 527 |
Flexural | |
Flexural Strength | 69,323 MPa ISO 178 |
Flexural Modulus | 2590,963 MPa ISO 178 |
Other | |
Impact Strength | 5,438 KJ/m2 ISO 179 |
Spool Type / Specs | |
1. Copymaster3D 1kg 2024 | |
Ø Ds | 195 mm |
Ø ds | 54 mm |
Ws | 58 mm |
ws | 52 mm |
Emty Spool Weight | 0,163 kg |
Spool Material | Carboard |
DB | 200 mm |
WB | 64 mm |
HB | 200 mm |
Empty Box Weight | 0,084 kg |
Box Material | Carboard |
